Published figures
- Free height of fall
- 150 cm
- Space required
- 128 m²
- Age range
- 3–12 years
- Dimensions (L × W × H)
- 16.04 × 6.91 × 4.53 m
As published by Buglo. Park Plan never estimates a figure.
Installation and tender detail
| Materials | stainless steel, powder coated steel, aluminium, wood, wooden, hdpe, polyethylene, hpl, polycarbonate |
| Colours | GreyYellowBlueseen in product image |
Description
Functionality: Balancing, Climbing, Sensory Integration, Sliding, Socialization. Assembly: Ceiling mounting, Ground installation. Compliant with EN 1176-1 (as stated by Buglo). Safety zone: 1091 x 1954 cm (128 m²). Materials: Soft conifer wood 90 x 90 mm, coreless, glued in layers with polyurethane glues, totally resistant to water. Patented system of connectors and clamps made of strong aluminium alloy. Slides made of stainless steel aisi 304. Metal sheet with a thickness of 2 mm formed in a cnc technique. Anti-slip anthracite 10mm hpl platform plate with a very high resistance to weather conditions and attrition. Plates of the walls made of colourful triple layered 15 mm hdpe polyethylene, in the highest quality, totally damp-proof. System of connectors and clamps made of strong aluminium alloy. Scale 1:200 hemispheric window with a diameter of 400 mm, made of heat- formed polycarbonate 5 mm wooden posts anchored to the ground with powder galvanized and powder coated steel anchors.
As written by Buglo.
Standards and certification
Published to EN 1176
Stated by Buglofor this range rather than on this product’s own sheet. Park Plan does not assess or verify compliance with any standard.
